Product Introduction
 |
 |
Imported material coverings All product coverings use imported materials |
Widened sweeping design 1950MM widened sweeping width design, sweeping range |
 |
 |
Dual brake systemHeli is the industry's first equipment supplier to introduce a dual brake system: electronic brake + mechanical brake in washing/sweeping machines |
All stainless steel chassisHeli is the industry's first equipment supplier to use "all stainless steel" material to build washing/sweeping machines. All products use stainless steel chassis. |
 |
 |
High-pressure washing deviceEquipped with a stainless steel high-pressure washing device, cleaning the garbage bin and side brush is easier and more convenient. |
Adjustable driving mode All products can be adjusted according to different scenarios |
Performance Parameters
|
Name |
Parameter Value/Specification |
|
Vehicle Model |
R-S1850 |
|
Sweeping Width |
1950mm |
|
Main Brush Size |
790*300mm |
|
Work Efficiency |
0-13650m²/h |
|
Travel Speed |
0-7km/h |
|
Water Tank Capacity |
180L |
|
Dustbin Capacity |
155L |
|
Working Time |
3-4H |
|
Side Brush Diameter |
500mm*4 |
|
Vacuum Filtration Area |
4.2m²*2 |
|
Tire Model |
Front 300*100mm Rear 350*100mm Solid Tire |
|
Braking System |
Mechanical Brake + Electronic Brake + Anti-rollback |
|
Battery Type |
Lead-acid maintenance-free/Lithium battery |
|
Battery Capacity |
48V/100Ah |
|
Drive Motor |
48V/1200W |
|
Main Brush Motor |
48V/950W |
|
Side Brush Motor |
48V/90W*2+48V/165W*2 |
|
Push Rod Motor |
48V/20W*4 |
|
Electric Dust Removal |
48V/120W*2 |
|
Fan |
48V/95W*2 |
|
Vehicle Weight |
670KG |
|
Vehicle Dimensions |
2600*1961*2051mm |
|
Packaging Dimensions |
2400*1850*2200mm |
|
Minimum Turning Radius |
670mm |
